HL-480B is Realtek 8192 WiFi chipset based 4G wireless WiFi for operators and telecom company.
Low cost cat4 LTE MIFI with Qualcomm 9*07 chipset.
150Mbps 4G pocket MIFI provide 2200mAh and 3000mAh (option) lithium battery.
| Character | Description | Explanation | |
| Product Name | HL-460 LTE CAT4 MIFI | ||
| ID Model | Size | 59*93.3*14.4mm | |
| Category | MIFI Router | 4G LTE Product | |
| LED Light | 4 | ||
| Users Manual | Support | ||
| Warranty | Support | ||
| Battery | 2100mA | ||
| Power suply | by battery | ||
| AC Adapter | The input voltage：100V~240V,50Hz~60Hz The output voltage：5V DC±10% The output current：1A |
||
| Baseband | CPU Model | ZTE7520V3 | |
| WiFi /Bluetooth chip model | RTL8189ES | ||
| SIM Card Slot | standard SIM, support 3V and 1.8V voltage ，compliance wirh ISIM Rel5 standard | ||
| Device Memory | Flash/RAM: 1G SPI Flash | ||
| External Storage | TF card, Up to 32GB compatible | ||
| USB Interface | 1* USB2.0 port,only need to meet the device mode,do not need to support host mode | ||
| Max WIFI users Number | 10 | 2.4GHz | |
| Inductor light | Support | ||
| RF | Rediofrequency Chipset | ZX234220FULLMASK_V1 | |
| Main antenna | build-in | ||
| Diversity reception antenna | build-in | ||
| WiFi antenna | build-in | ||
| LTE Frequency | FDD B3 B7 B20 | ||
| WCDMA Bands | B1/B8 | ||
| Diversity recept bands | support LTE | Qualcomm Type 3i antenna reception technology | |
| Wireless MIMO technology | 2 × 2 download SU-MIMO | Single antenna transmission, dual antenna reception | |
| Wireless transmit power | TDD-LTE：23dbm±2dbm FDD-LTE：23dbm±2dbm TD-SCDMA：23dbm±2dbm WCDMA :23dbm±2dbm |
||
| WiFi bands | support 2.4GHz | ||
| WiFi MIMO | sopport 802.11b/g/n 2*2 MIMO | ||
| Peak Rate and Standard | LTE | TDD-LTE:Cat4 130 Mbps DL / 35Mbps UL FDD-LTE Cat4 150 Mbps DL / 50Mbps UL |
Theoretical peak, depend on test environment, bandwidth and channel settings |
| TD-SCDMA | DL 4.2Mbps UL 2.2Mbps |
||
| WCDMA | DL 21Mbp UL 5.76Mbps |
||
| 3GPP/3GPP2 protecol | LTE FDD/TDD Rel 10 | ||
| WiFi standard | 802.11 b/g/n(1*1 only) | ||
| WiFi Authentication | defult WPA-PSK/WPA2-PSK | The default authentication mode can be customized | |
| WPS | support | ||
| Button | Switch button | 1 | |
| Reset button | 1, Pinhole | ||
| WPS button | N/A | ||
| Working Environment | Operating temperature | -10~ 60° C | |
| Storage temperature | -45 ~ 85° C | ||
| Humidity | 10%~ 95% | ||
| Standby time | Can reach more than 300 hours | WIFI off | |
| Working time | Can reach more than 8 hours | According to actual use | |
